Accuracy: ±4% of reading
Accuracy Class: ±4% of reading
Brand Name: NONE,Hioki
Current Resolution: 1 mA
DIY Supplies: Electrical
Dimensions: 18 * 16 * 6cm
Display Type: Digital Only
High-concerned chemical: None
Insulation Resistance: 100 to 4,000 MΩ
Lower Limit Resistance: 0.05 to 1 MΩ in 5 ranges
Measuring Range: 100 to 4,000 MΩ
Model Number: IR4053-10
Operating Temperature: -10 to 50
Origin: Mainland China
Place of Origin: Japan
Power Supply: 4 AA batteries
Product Weight: 600g
Response Time: 4 seconds
Speed Range: 10 m/s
Testing Voltage: 50 to 1,000 V
Time Resolution: 1ms
insulation measurement: 1 second
insulation resistance measurement: 100 to 4,000 MΩ
voltage range: 50 to 1,000 V
|
Rated Output Voltage
|
PVΩ measurement: 500/1,000 VDC, insulation resistance measurement: 50 to 1,000 VDC in 5 ranges
|
|
Effective Maximum Indicated Value
|
PVΩ measurement: 2,000/4,000 MΩ, insulation resistance measurement: 100 to 4,000 MΩ
|
|
Measurement Range
|
0.2 to 500 MΩ (±4% of reading), 501 to 2,000 MΩ (±8% of reading), 0.2 to 1,000 MΩ (±4% of reading), 1,010 to 4,000 MΩ (±8% of
reading), 0 to 0.199 MΩ (±2% of reading ±6 digits) PVΩ measurement |
|
Accuracy
|
Insulation resistance measurement: ±4% of reading
|
|
Lower Limit Resistance
|
0.05 to 1 MΩ in 5 ranges
|
|
Overload Protection
|
600 VAC (10 seconds), 1,200 VDC (10 seconds)
|
|
DC Voltage Measurement
|
4.2 V (0.001 V resolution) to 1,000 V (1 V resolution) in 4 ranges with ±1.3% of reading ±4 digits
|
|
AC Voltage Measurement
|
420 V (0.1 V resolution)/600 V (1 V resolution) in 2 ranges with 50/60 Hz and ±2.3% of reading ±8 digits
|
|
Display
|
Backlit semi-transmissive FSTN LCD
|
|
Response Time
|
PVΩ measurement: 4 seconds, insulation resistance measurement: 1 second
|
|
Function
|
Live circuit indicator, automatic electric discharge, automatic DC/AC detection, comparator, drop-proof, auto power save
|
|
Power Supply
|
4 AA batteries
|
|
CE Compliant
|
Yes
|
|
Product Length
|
2.09" (53 mm)
|
|
Product Width
|
6.26" (159 mm)
|
|
Product Height
|
6.97" (177 mm)
|
|
Product Weight
|
21.2 oz (600 g)
|
